Lesson 2 of 6 · Circulation and weather
Uneven heating sets the air in motion
9 minute lesson · 3 checks along the way
Your goal for this lessonExplain how pressure gradients, rotation, and friction shape winds, while treating circulation cells as an average rather than a daily forecast.
Follow a linked name to explore its archive card. “Back to your lesson” brings you to the same part of the reading.
Words with a dotted underline open a short definition right here in the lesson.
Follow an imbalance around the planet
Sunlight reaches different places at different angles, and land and ocean respond to heating at different rates. These differences help create contrasts in temperature and . A horizontal pushes air toward lower pressure. Atmospheric motion, together with ocean currents, redistributes energy from regions receiving a surplus toward regions losing more energy. The pattern changes with the seasons, continents, mountains, and the weather systems already in motion.
An air parcel does not normally travel straight from a map’s high-pressure center to its low-pressure center. Viewed from the rotating Earth, moving air is deflected to its right in the Northern Hemisphere and to its left in the Southern Hemisphere. This changes direction without supplying the original heating. Friction near the surface and other forces also matter. A map of pressure is therefore useful evidence about wind, but not a complete wind forecast by itself.
Read the cells as a long-term pattern
Diagrams often show three broad cells in each hemisphere: Hadley, Ferrel, and polar cells. They summarize averages across time and longitude. Tropical rising air, subtropical descending regions, midlatitude storms, and high-latitude circulation contribute differently to the whole pattern. The Ferrel cell especially represents the average effects of moving weather systems; it should not be imagined as a single permanent conveyor belt followed by every parcel.
Seasonal shifts in heating change where rising air and rainfall are concentrated. Mountains and coastlines further reshape the flow. Within a weather system, surface convergence near a low-pressure area can accompany rising air and clouds, while sinking air often reduces cloudiness. Those are useful tendencies with conditions attached. A low-pressure label cannot specify rainfall amount without moisture, stability, lifting, and the system’s evolution; a high can also contain fog or low cloud.
Check 1 of 3
10 pointsUse the reading above. You can try again without losing points.
Work through a decision
Separate transport from a forecast
Imagine tracking a patch of air moving east at a steady 15 meters per second for two hours. Ignore acceleration, vertical motion, and changes in direction. Two hours equals 7,200 seconds, so the traveled distance is 15×7,200 = 108,000 meters, or 108 kilometers. If a passive tracer follows that exact flow, this gives its idealized displacement, not the future size or intensity of a storm.
Now compare a second invented pressure pattern with the same 8-hectopascal difference spread across twice the distance. Its average pressure gradient has half the magnitude. For the same air , the associated pressure-gradient acceleration is also halved. That does not guarantee half the wind speed: rotation, friction, starting motion, and elapsed time affect the resulting wind. Distinguishing a force from an already established velocity prevents a misleading shortcut.
Check 2 of 3
10 pointsUse the reading above. You can try again without losing points.
Watch the pattern evolve
Repeated satellite images show fronts and cloud systems changing across large regions. They complement surface stations, balloons, aircraft observations, and computer models. Clouds can trace some air motion, but they also form and evaporate, so a moving cloud edge need not mark the same material throughout a sequence. and water-vapor channels add information beyond a daylight view, each with its own sensitivity and limitations.
A useful investigation compares several timestamps, records the interval between them, and checks the image scale. It then asks which changes represent transport and which could represent growth or dissipation. Forecast ensembles explore how plausible initial states and model differences affect the outcome. Agreement among members supports confidence in a particular feature; disagreement identifies uncertainty that one smooth, colorful animation can otherwise conceal.
GOES-17’s ABI viewed the Western Hemisphere on May 20, 2018. This GeoColor product combines visible and infrared information to give an intuitive view of clouds and the surface. NOAA released it as preliminary imagery during post-launch testing.
Look closely
Trace a cloud pattern in this single frame. What additional observations would let you estimate motion, and why might a changing cloud edge fail to follow the same air parcel?
See what to notice
Time-stamped, geometrically aligned frames can show displacement. Cloud formation and evaporation also change the outline, so apparent pattern motion must be checked before treating it as a passive wind tracer.
Check 3 of 3
10 pointsUse the reading above. You can try again without losing points.
Put it together
Your lesson progress
Each check connects to a part of the story. Complete all 3 to earn your 25-point lesson bonus.
