Lesson 2 of 6 · Icy geology and a coupled pair
Compare Pluto and Charon
9 minute lesson · 3 checks along the way
Your goal for this lessonUse surface and orbital observations to compare Pluto and Charon while keeping image appearance, mass, and interior models separate.
Follow a linked name to explore its archive card. “Back to your lesson” brings you to the same part of the reading.
Words with a dotted underline open a short definition right here in the lesson.
Two worlds, different surface records
New Horizons flew through the Pluto system in July 2015, resolving landscapes that distant telescopes could not map in comparable detail. Pluto has rugged water-ice terrain and broad deposits of more ices, including nitrogen. At its cold surface, water ice can provide strong terrain while nitrogen ice deforms more readily. The word ice therefore does not specify one mechanical behavior or one substance.
Charon shows extensive craters, fractures, and smoother regions with a different surface history. Comparing equal-quality observations helps reveal these differences, but color alone is not a chemical identification. The paired archive view combines separate enhanced-color observations. Its processing supports surface comparison, while the displayed gap is deliberately unlike the true separation. A composite is useful evidence when its construction is understood.
Enhanced-color New Horizons observations from July 14, 2015 are combined into this Pluto–Charon comparison. Both bodies use matching color and brightness processing and approximately correct relative sizes. Their displayed separation is not to scale. The composite emphasizes contrasting surface regions; it is not one camera exposure of the two bodies at this apparent spacing.
Look closely
Which comparison does the source permit, and which tempting measurement would be invalid?
See what to notice
The matching processing supports comparing their surface appearances and approximate relative sizes. Measuring the gap between them on this composite would not determine their actual separation or barycenter. Those require orbital observations and a physical scale.
Check 1 of 3
10 pointsUse the reading above. You can try again without losing points.
Follow both members of the pair
Pluto and Charon both orbit their shared center of mass, or . Charon is large enough relative to Pluto that this point lies outside Pluto’s surface. Neither body is an absolutely fixed center. Their mutual motion lets astronomers infer masses when combined with a measured physical separation and period. Apparent size or brightness alone cannot provide those masses without additional assumptions.
The pair is mutually tidally locked: each rotates once during their approximately 6.4-day mutual orbital period, keeping the same hemisphere toward the other. They still rotate relative to distant stars. Locking does not mean that the surfaces stop moving in an inertial frame. It also differs from saying that Pluto’s orbit around the Sun takes 6.4 days; that much larger orbit takes about 248 Earth years.
Work through a decision
Locate a fictional center of mass
Imagine two ideal spherical bodies separated by 22,000 kilometers between their centers. The larger has ten times the smaller body’s mass and a radius of 1,200 kilometers. Let r be the barycenter’s distance from the larger center. Equal mass moments require 10r = 22,000 − r, so 11r = 22,000 and r = 2,000 kilometers. The point lies 800 kilometers above the larger body’s surface.
The larger body makes a smaller orbit around that point; the smaller body is 20,000 kilometers from it. These invented values demonstrate the method, not a new determination of Pluto’s dimensions. The calculation depends on mass ratio and center-to-center separation. Replacing a mass ratio with a diameter ratio would generally fail, because volume and density also matter. A large companion shifts the barycenter without making either object stationary.
Locate a shared center of mass
Original diagram of the invented pair in the lesson, not measured Pluto–Charon dimensions. The center distances and larger body’s radius share a scale; the smaller body’s radius is schematic because the example does not specify it. Mass moments balance at the barycenter, which lies outside the larger body. No orbit paths or viewing perspective are implied.
Open full-size diagram in a new tab: Locate a shared center of massCheck 2 of 3
10 pointsUse the reading above. You can try again without losing points.
Connect landscapes to bounded explanations
Pluto’s smooth nitrogen-rich plains and varied terrain suggest that a small distant world can redistribute material. Their appearance does not require every region to have the same age. Crater counts, flow patterns, spectra, and models of ice behavior help evaluate . A sparse crater population can indicate renewal under a stated impact model; it is not an absolute date read directly from a photograph.
Likewise, models that allow a buried ocean are inferences about interior structure, not pictures of exposed liquid. Testing them requires several constraints rather than a single pale patch. Pluto and Charon are valuable precisely because their close association permits comparison while their histories differ. Classifications tell us how to organize such worlds, but detailed measurements reveal which processes shaped them and which questions remain open.
Check 3 of 3
10 pointsUse the reading above. You can try again without losing points.
Put it together
