Lesson 3 of 5 · Solar & lunar eclipses
When the shadows line up
8 minute lesson · 3 checks along the way
Your goal for this lessonDistinguish solar and lunar eclipses, explain why they do not happen every month, and separate a geometry model from a safe observing plan.
Follow a linked name to explore its archive card. “Back to your lesson” brings you to the same part of the reading.
Words with a dotted underline open a short definition right here in the lesson.
Which body casts the shadow?
A solar eclipse happens when the Moon passes in front of the Sun from an observer’s viewpoint and its shadow reaches Earth. This requires the new-Moon part of the phase cycle. A lunar eclipse happens when the Moon passes through Earth’s shadow, requiring the full-Moon part of the cycle. The bodies casting and receiving the shadow distinguish the two events.
The type of eclipse also affects who can see it. A total solar eclipse follows a relatively narrow track across Earth; a nearby observer may see only a partial eclipse. A lunar eclipse can be observed from a much broader part of Earth where the Moon is above the horizon. Weather and local visibility still matter, even when the large-scale geometry permits a view.
Check 1 of 3
10 pointsUse the reading above. You can try again without losing points.
Work through a decision
A tilted orbit usually misses
The Moon’s orbital plane is tilted by about five degrees relative to Earth’s orbital plane around the Sun. Most new Moons pass above or below the precise alignment needed to cast a shadow onto Earth. Most full Moons miss Earth’s shadow too. A flat phase diagram hides that extra dimension, making eclipses look more automatic than they really are.
The two points where the Moon’s orbit crosses Earth’s orbital plane are called . Eclipses become possible when the phase alignment occurs near a node during an eclipse season. In the activity, compare near-new and near-full configurations with a near-node or off-node position. Predict which shadow can meet which body. The simplified, exaggerated geometry explains the condition; it does not calculate a real eclipse date or visibility map.
Add the missing dimension
Why is there not an eclipse every month?
The Moon’s orbit is tilted about 5° to Earth’s orbital plane around the Sun. Compare new and full Moon, then move the alignment near or away from a plane crossing—a node.
Looking along Earth’s orbital plane
The alignment misses
This is a new Moon, but the Moon is well away from the orbital plane crossing. Its shadow passes to one side of Earth. A new Moon alone is not enough for a solar eclipse.
Being near a node at the right phase makes an eclipse possible. The exact alignment, distances, and viewing location determine what kind of eclipse is seen.
What does this comparison show—and leave out?
The orbit stays tilted in both examples. “Near” places the Moon exactly at a crossing for a clear comparison; “away” puts it about 5.1° above or below the Earth–Sun plane. Changing the choice represents different orientations of the tilted orbit relative to the Sun, not bending the Moon’s orbit flat.
The band only indicates which way a shadow extends. It does not draw the umbra, penumbra, or an eclipse path on Earth. Real geometry includes the Sun’s size, varying distances, and changing orbital orientation. This is a comparison of necessary alignment conditions, not an eclipse forecast or a prediction of totality.
Sources: NASA: eclipses and the Moon ↗ and NASA: the Moon’s orbit and nodes ↗.
Check 2 of 3
10 pointsUse the reading above. You can try again without losing points.
Alignment alone does not determine the view
Because the Moon’s distance changes along its elliptical orbit, its apparent size changes. When its disk looks large enough and the observer lies in the right shadow region, it can cover the Sun completely. When it appears smaller, a central alignment can leave a bright ring, producing an annular eclipse. Partial views occur where only part of the solar disk is covered.
During a total lunar eclipse, the Moon can become coppery or red rather than vanish completely. Some sunlight passes through Earth’s atmosphere and is bent into the shadow; the atmosphere filters that light. Conditions in Earth’s air affect the resulting appearance. A red lunar image is therefore evidence about illumination and atmosphere, not evidence that the Moon has suddenly begun glowing with its own heat.
The Sun observed by the Solar Dynamics Observatory on March 28, 2013. Orange represents extreme-ultraviolet light. The irregular dark patch is a coronal hole in the solar atmosphere; this is not a photograph of a solar eclipse or the Moon blocking the Sun.
Look closely
A dark patch is visible on the Sun. Is darkness alone enough evidence to call an image a solar eclipse?
See what to notice
An eclipse requires a particular alignment and an object blocking light along the observer’s line of sight. The source identifies this patch as solar atmospheric structure recorded in extreme ultraviolet. Check the instrument, caption, and observing geometry before assigning a cause to a dark region.
Study the geometry safely
This lesson uses diagrams and recorded imagery; no direct Sun observation is needed. Ordinary sunglasses do not make solar viewing safe. A camera, telescope, or binoculars can concentrate dangerous sunlight, and wearing eclipse glasses does not make looking through those instruments safe. Any real solar observing activity needs the appropriate equipment and NASA’s current, complete safety guidance before it begins.
Lunar eclipse observation does not carry that direct-Sun hazard, because you are looking at the Moon. Still, a lesson diagram is not a local forecast or an observing plan. For a real event, verify the eclipse type, location, date, and visibility with an authoritative prediction. The same geometry can produce different experiences for different observers, so an image from another town does not establish your own view.
Check 3 of 3
10 pointsUse the reading above. You can try again without losing points.
Put it together
Your lesson progress
Each check connects to a part of the story. Complete all 3 to earn your 25-point lesson bonus.
