Lesson 6 of 6 · Retirement and final science archives
End operations without ending the evidence
8 minute lesson · 3 checks along the way
Your goal for this lessonConnect retirement planning with documented, reusable scientific archives.
In this lesson 3 sections · 3 checks
Using archive links & definitions
Follow a linked name to explore its archive card. “Back to your lesson” brings you to the same part of the reading.
Words with a dotted underline open a short definition right here in the lesson.
Read & understand
The last signal is one boundary
A mission’s operating lifetime eventually ends, but its responsibilities include more than receiving a final transmission. Retirement planning considers the spacecraft’s destination or orbit, remaining resources and the applicable protection or disposal requirements. The relevant choices differ for an Earth satellite, a planetary orbiter and an escaping spacecraft.
End-of-mission actions need resources and controllability, so waiting until every reserve is exhausted can remove options. A planned final maneuver and an unexpected loss of communication are different outcomes. Historical summaries should describe which occurred and what the available evidence establishes.
Check 1 of 3
10 pointsUse the reading above. You can try again without losing points.
Read & understand
Preserve a measurement’s meaning
A scientific archive contains more than image files. Later users need units, time conventions, instrument settings, calibration information, geometry, processing history and known limitations. NASA’s Planetary Data System preserves planetary-science data with documentation intended to support their interpretation and reuse.
Imagine two archived temperature columns containing the same numbers. One uses kelvin; the other uses degrees Celsius. Without unit labels, apparently simple comparisons can be wrong. Likewise, a corrected image and its raw detector values serve different purposes. Their relationship should be documented so a future researcher can reconstruct how the product was made.
Voyager 2 recorded this view of Saturn’s northern atmosphere on August 18, 1981. The archived image preserves an observation from a particular time and viewing geometry; later studies need the calibration and processing context behind the displayed colors and features.
Look closely
What would a new study of cloud motion need beyond this single displayed frame?
See what to notice
It would need suitably timed comparison observations, geometry, scale and processing information. One preserved image is evidence of appearance at one time, not a complete motion measurement.
Check 2 of 3
10 pointsUse the reading above. You can try again without losing points.
Read & understand
Make later analysis possible
A mission can generate new scientific results after the spacecraft stops operating because researchers can ask new questions of preserved observations. This is not a new transmission from the retired spacecraft. It is a new interpretation, comparison or processing of evidence already collected.
For a fictional archive handoff, check whether another person can identify the observation, locate its calibration, understand missing values and reproduce the processing steps. Keeping the file alone passes only the simplest test. A useful archive preserves enough context to evaluate a claim and, where possible, challenge or improve the original analysis.
Check 3 of 3
10 pointsUse the reading above. You can try again without losing points.
Put it together
Your lesson progress
Each check connects to a part of the story. Complete all 3 to earn your 25-point lesson bonus.
Explore further · Optional
Go to the source
Explore the evidence behind this lesson. These optional readings and videos open in a new tab.
